DIMENSIONS

• Door leaf (dimensions in rebate) 924 x 2022 mm
• Door (on the external side of the door frame) 1004 x 2071 mm

STRUCTURE

• Door leaf: wooden rail and stile set topped with two HDF boards, the core made of special POL-SKONE structure, door leaf thickness: 50 mm, door leaf thickness: 50 mm
• Door frame: metal
• Oaken threshold

WAY OF OPENING

• Opened outwards or inwards

HARDWARE

• Strip type mortise four-point bolt lock (2 bolts, 2 hooks), spacing: 92 mm, colour: silver
• 4 pivot hinges adjustable in 3 planes in silver colour, 5 anti-burglar bolts

EQUIPMENT

• Recommended equipment option: the GARDA rose, the class 3 GARDA handle (spacing: 92 mm), class 6 cylinders, viewer available at extra charge
• The standard includes a borehole for the GARDA handle* (spacing: 92 mm)
• Adaptability of the ES1 averse electric door strike by Bira
• NOTE! To ensure that the door meets anti-burglar specifications, door handles should comply with min. class 3 anti-burglar resistance rating in accordance with the PN-EN 1906:2012 standard whereas door lock cylinders should comply with min. class 4 key-related resistance rating and min. class 1 attack resistance rating according to the PN-EN 1303:2007+AC:2008 standard.

TECHNICAL SPECIFICATIONS

• Anti-burglar resistance: class RC3**
• Acoustic insulation: class 32 dB

RC3 with wooden door frame

DIMENSIONS (on the external side of the door frame)

• Door (on the external side of the door frame) 1012 x 2075 mm
• Optional dimensions: 880×1950 mm; 880×2000 mm; 880×2075 mm; 980×1950 mm; 980×2000 mm; 980×2075 mm; 1012×1950 mm; 1012×2000 mm

STRUCTURE

• Door leaf: wooden rail and stile set topped with two HDF boards, the core made of special POL-SKONE structure, door leaf thickness: 50 mm
• Door frame: standard – fixed wooden (adaptability of widening panels); optional – door frame with one-side adjustment
• Oaken threshold, height: 20 mm

WAY OF OPENING

• Opened outwards or inwards

HARDWARE

• Strip type mortise four-point bolt lock (2 bolts, 2 hooks), spacing: 92 mm, colour: silver
• 4 pivot hinges adjustable in 3 planes in silver colour, 5 anti-burglar bolts

EQUIPMENT

• ∙∙Recommended equipment option: the GARDA rose, the class 3 GARDA handle (spacing: 92 mm), class 6 cylinders, viewer available at extra charge
• The standard includes a borehole for the GARDA handle* (spacing: 92 mm)
• Adaptability of the ES1 averse electric door strike by Bira
• NOTE! To ensure that the door meets anti-burglar specifications, door handles should comply with min. class 3 anti-burglar resistance rating in accordance with the PN-EN 1906:2012 standard whereas door lock cylinders should comply with min. class 4 key-related resistance rating and min. class 1 attack resistance rating according to the PN-EN 1303:2007+AC:2008 standard.

TECHNICAL SPECIFICATIONS

• Anti-burglar resistance: class RC3**
• Acoustic insulation: class 32 dB
