DOOR LEAF STRUCTURE
- rebated system or the DUO non-rebated system
- rail and stile set topped with two flush HDF boards covered with veneered surface or the LAMISTONE CPL, SILKSTONE surface
GLAZING
- exchangeable: Decormat white tempered glass, Decormat brown, graphite satin (only patterns W01-W04, see the glazing table)
- exchangeable – tempered glass: white, brown (only patterns W08), white (only patterns W07)
- exchangeable – tempered glass: white matt, brown matt, graphite satin (only pattern W05)
- exchangeable – tempered glass: white pane (only pattern W01-W04)
STANDARD EQUIPMENT
REBATED SYSTEM
- Single-point mortise lock, spacing: 72 mm, key-operated (WK), for cylinder (WB) or for bathroom lock (WC)
- Hinges: door in the colours of RETRO/ LIMBA/ collection IV (a complete set including: a door leaf and a wooden or a DIN frame – adjustable screw-in pivot type; veneered doors: collection I, II, III, LAMISTONE CPL, SILKSTONE (a complete set including: a door leaf and a wooden or a DIN frame – screw-in pivot type; leaves (for standard metal frames) – screw-in pivot type (“70”, “80”- 2 units, “90”- 3 units)
- Hinges: screw-in pivot type (“60”, “70”, “80” – 2 units; “90” – 3 units)
NON-REBATED SYSTEM
- Magnetic mortise lock (colour: chrome – satin), key-operated WK, for bathroom lock WC – spacing: 90 mm; for cylinder WB – spacing: 85 mm
- Hidden non-rebated hinges (DUO non-rebated system) (“60”, “70” ,“80” – 2 units; “90” – 3 units
DOOR LEAF DIMENSIONS
- The single leaf type: “70”; “80”; “90” – option available at extra charge – “100”
- The double leaf type: “70”+“70”; “70”+“80”; “70”+“90”; “80”+“80”; “80”+“90”; “90”+“90”
