SPECIFICATIONS
- Mechanical class: mechanical resistance requirement class 3, i.e. heavy service conditions according to PN-EN 1192:2001
- Acoustic insulation: class Rw = 37 dB
STRUCTURE
- Rebated door leaf: wooden rail and stile set, chipboard core
- Door leaf topped with 5 mm thick HDF board on both sides with 1 mm thick lead insert
- The door leaf has two-sided 1 mm thick lead insert (2 mm in total for the leaf)
- Door frame: the GAMMA fixed or adjustable wooden door frame with lead insert and the GAMMA fixed or adjustable metal door frame with lead insert made of 1.5 mm sheet
STANDARD ACCESSORIES
- Single-point mortise lock
- 4 pivot hinges adjustable in 3 planes
- Drop seal
AUXILIARY EQUIPMENT
- Cylinders
- Additional mortise lock
- Stainless steel panels glued to the door leaf bottom side or at the handle height
- Automatic door closer
- Electric strike
- Panic bar
- Electromagnetic lock
- Mortise contact (wooden door frame)
- Card reader lock
MODELS
