STRUCTURE
- WOODEN: a single frame window and balcony door, the leaf thickness: 68 mm, the framethickness: 171 mm, the S-system glazing bead or the Type C glazing bead, the low mortise threshold with thermal insulation for the disabled friendly rooms
- WOOD ALUMINIUM: a single frame wood and aluminium window, wooded and aluminium, thethickness of the leaf with aluminium: 82 mm, the thickness of the frame with aluminium: 190 mm,a low mortise threshold with thermal insulation for the disabled friendly rooms
FRAME AND LEAF MATERIAL
- Glued laminated pine wood, optional: oak wood
FINISH
- WOODEN: water soluble covering paints or transparent paints, a three-layer covering system, a four-layer transparent system
- WOOD ALUMINIUM: water soluble covering paints or transparent paints, a three-layer covering system, a four-layer transparent system, powder painted aluminium, the RAL basic colours: 9016,9007, 9006, 9005, 8019, 8017, 8011, 8007, 8003, 8001, 7042, 7035, 7001, 6029, 6005, 5015, 5013,5010, 3003, 3002, 1033, 1013 (the other colours of the RAL palette are available at extra charge)
GLAZING
- Glazing set 4 Float / 16 Argon / 4 Thermofloat 1.0 Ug=1.0 W/m2K in accordance with EN 673 g=50% in accordance with EN 410 Glass types available on request: laminated, anti-burglar (P2,P4), sound absorbing, ornamental, Antisol (body-tinted), Stopsol (a mirror reflection effect), self-cleaning, a thermopanel, a warmspacer edge, a triple glass pane set 4 Thermofloat / 10 Argon / 4 Float / 10 Argon / 4 Thermofloat Ug=0.8 W/m2K in accordance with EN 673 g=53% in accordance with EN 410
HARDWARE
- Circumferential Roto Life with two-dimensional adjustment, 4 security points, microventilation
- Items available on request: a double-sided handle with a key cylinder
MUNTINS (optional)
- Structural (58, 78 mm), Vienna type (glued), wooden fixed by means of clasp locks, aluminium between glass panes (8, 18, 26, 45 mm)
WEATHER STRIP
- Roto system weather strip
WAY OF OPENING
- Fixed leaf, sliding leaf (left-hand or right-hand) / fixed leaf, 2 sliding leaves (left-hand and right-hand) / 2 side fixed leaves, left-hand sliding leaf / right-hand sliding leaf, 2 sliding leaves (left-hand and right-hand) / middle fixed leaf
ADDITIONAL WINDOW ACCESSORIES
- Renson air inlet, an aluminium cap for the threshold
