STRUCTURE
- Single frame window and balcony door, the leaf thickness: 68 mm, the frame thickness: 68 mm, the S-system glazing bead or the R=5mm glazing bead, the Komfort low aluminium threshold is available on request
FRAME AND LEAF MATERIAL
- Glued laminated pine wood, optional: oak or meranti
FINISH
- Water soluble covering paints or transparent paints, a three-layer covering system, a four-layer transparent system
GLAZING
- Glazing set 4 Float / 16 Argon / 4 Thermofloat 1.0 Ug=1.0 W/m2K in accordance with EN 673 g=50% in accordance with EN 410 Glass types available on request: laminated, anti-burglar (P2, P4), sound absorbing, ornamental, Antisol (body-tinted), Stopsol (a mirror reflection effect), self-cleaning, a thermopanel, a warm spacer edge, a triple glass pane set 4 Thermofloat / 10 Argon / 4 Float / 4 Thermofloat Ug=0.8 W/m2
K in accordance with EN 673 g=53% in accordance with EN 410
HARDWARE
- Circumferential Roto Patio 6080 with three-dimensional adjustment, a security protection set, a handle incorrect position lock
- Items available on request: a double-sided handle with a key cylinder
HINGE CAPS
- Standard colours: white, medium brown
- Optional: silver
DRIP CAP
- Aluminium drip cap in the colours of: white, brown (standard); silver, olive, golden (optionally)
MUNTINS
- Structural (58, 78 mm), Vienna type (glued), wooden fixed by means of clasp locks, wooden fix on hinges, aluminium between glass panes (8, 18, 26, 45 mm)
WEATHER STRIP
- Two profile weather strips: the main strip and the edge strip
WAY OF OPENING
- Layouts: 330, 321, 431, 532, 541, 550, 633, 651, 743, 761, 770, 871
ADDITIONAL WINDOW ACCESSORIES
- Handles, the Renson air inlet
